LD-Series

LD Series Dewars

For the safe storage and dispensing of small amounts of liquid nitrogen

FEATURES

  • Rugged ribbed high-strength aluminum body, magneformed necktube design, and more durable paint
  • Snap-on cap and necktube assures a tight closure
  • Advanced insulation materials assure high thermal efficiency
  • Made in USA
Withdrawaldevice

Liquid Withdrawal Device (LWD)

For convenient, pressurized dispensing of liquid nitrogen

The Liquid Withdrawal Device (LWD) provides convenient pressure transfers of liquid nitrogen from 25LD, 35LD and 50LD Dewars.

The device clamps directly to the special neck flange that is found under the plastic trim collar around the neck of these containers. Flow rates up to 8 liters per minutes are possible at operating pressures up to 7.25 psig (0.5 bar/50 kPa).

Liquid can be dispensed directly from the LWD via the spout provided, or through a standard cryogenic hose connected to the liquid outlet.

LWD top_2_web
LWD top_3_web
